Модель:NMRV
- Размер: 30 - 40 - 50 - 63 - 75 - 90 - 110 - 130 - 150
- Передаточное отношение: "i" = 5:1 - 100:1
- Мощность: 0,06 - 7.5 квт
- Крутящий момент: 1,8 - 1500 Нм
Изготавливается с применением литья под давлением.
Работает по принципу червячной передачи.
Помещен в модернизированный универсальный корпус, позволяющий монтировать его в различном положении.
Имеет шесть вариантов крепления и семь вариантов исполнения.
ОБЩЕЕ ОПИСАНИЕ
Таблица 1. Схема типового обозначения.
|
тип |
типоразмер |
передаточное число |
исполнение |
электро-двигатель |
монтажная позиция |
|||
|
двухсторонний входной вал |
цилиндрический выходной вал |
выходной фланец |
реактивная штанга |
|||||
|
NMRV |
030 - 130 |
5 - 3200 |
E |
SS - односторонний |
FL |
A |
мощность и обороты электро-двигателя |
монтажные позиции |
|
NRV |
||||||||
|
PCRV |
DS - двухсторонний |
|||||||
|
DRV |
||||||||
Пример условного обозначения в заказе.
Мотор-редуктор NMRV – 75 – 20 – 70 – B3 – 0.37, где:
- NMRV – тип мотор-редуктора;
- 75 – типоразмер;
- 20 – передаточное чиcло;
- 70 – частота вращения выходного вала, об/мин;
- B3 – вариант крепления мотор-редуктора;
- 0,37 – мощность электродвигателя.
Рис.1. Варианты исполнения.
Рис. 2. Монтажные позиции.
Таблица 2. Технические характеристики (n1=1400).
|
Мощность двигателя, кВт |
Частота вращения выходного вала, об/мин |
Крутящий момент, Нм |
Сервис-фактор |
Передаточное число |
Тип мотор-редуктора |
Двигатель IEC |
Радиальная нагрузка, Н |
|
0,06 |
280.0 |
1.8 |
6.2 |
5 |
NMRV025 |
56A4 |
439 |
|
186.7 |
2.6 |
4.2 |
7.5 |
503 |
|||
|
140.0 |
3.4 |
3.5 |
10 |
553 |
|||
|
93.3 |
4.9 |
2.5 |
15 |
633 |
|||
|
70.0 |
6.1 |
2.0 |
20 |
697 |
|||
|
46.7 |
8.2 |
1.6 |
30 |
798 |
|||
|
35.0 |
10 |
1.3 |
40 |
878 |
|||
|
28.0 |
12 |
0.9 |
50 |
946 |
|||
|
23.3 |
14 |
0.7 |
60 |
1006 |
|||
|
180.0 |
2.7 |
4.8 |
5 |
NMRV025 |
63А6 |
509 |
|
|
120.0 |
4.0 |
3.2 |
7.5 |
583 |
|||
|
90.0 |
5.2 |
2.7 |
10 |
641 |
|||
|
60.0 |
7.4 |
1.9 |
15 |
734 |
|||
|
45.0 |
9.3 |
1.4 |
20 |
808 |
|||
|
30.0 |
12 |
1.2 |
30 |
925 |
|||
|
22.5 |
15 |
0.9 |
40 |
1018 |
|||
|
18.0 |
18 |
0.7 |
50 |
1096 |
|||
|
280.0 |
1.8 |
10.1 |
5 |
NMRV030 |
56A4 |
597 |
|
|
186.7 |
2.6 |
6.9 |
7.5 |
683 |
|||
|
140.0 |
3.4 |
5.4 |
10 |
752 |
|||
|
93.3 |
4.7 |
3.8 |
15 |
861 |
|||
|
70.0 |
6.0 |
3.0 |
20 |
948 |
|||
|
56.0 |
7.0 |
3.0 |
25 |
1021 |
|||
|
46.7 |
8.0 |
2.5 |
30 |
1085 |
|||
|
35.0 |
9.7 |
1.9 |
40 |
1194 |
|||
|
28.0 |
11 |
1.5 |
50 |
1286 |
|||
|
23.3 |
13 |
1.3 |
60 |
1367 |
|||
|
17.5 |
14 |
0.9 |
80 |
1504 |
|||
|
15.0 |
18 |
0.9 |
60 |
NMRV030 |
63А6 |
1583 |
|
|
18.0 |
18 |
2.3 |
50 |
NMRV040 |
63А6 |
2868 |
|
|
15.0 |
21 |
1.9 |
60 |
3047 |
|||
|
11.3 |
24 |
1.4 |
80 |
3354 |
|||
|
9.0 |
27 |
1.2 |
100 |
3490 |
|||
|
0,09 |
560.0 |
1.4 |
5.9 |
5 |
NMRV025 |
56A2 |
349 |
|
373.3 |
2.0 |
3.9 |
7.5 |
399 |
|||
|
280.0 |
2.6 |
3.4 |
10 |
439 |
|||
|
186.7 |
3.8 |
2.4 |
15 |
503 |
|||
|
140.0 |
4.9 |
1.9 |
20 |
553 |
|||
|
93.3 |
6.7 |
1.3 |
30 |
633 |
|||
|
70.0 |
8.3 |
1.1 |
40 |
697 |
|||
|
56.0 |
10 |
0.9 |
50 |
751 |
|||
|
280.0 |
2.7 |
4.1 |
5 |
NMRV025 |
56B4 |
439 |
|
|
186.7 |
3.9 |
2.8 |
7.5 |
503 |
|||
|
140.0 |
5.1 |
2.4 |
10 |
553 |
|||
|
93.3 |
7.3 |
1.6 |
15 |
633 |
|||
|
70.0 |
9.2 |
1.3 |
20 |
697 |
|||
|
46.7 |
12 |
1.1 |
30 |
798 |
|||
|
35.0 |
15 |
0.9 |
40 |
878 |
|||
|
560.0 |
1.4 |
8.8 |
5 |
NMRV030 |
56A2 |
474 |
|
|
373.3 |
2.0 |
6.5 |
7.5 |
542 |
|||
|
280.0 |
2.6 |
5.0 |
10 |
597 |
|||
|
186.7 |
3.7 |
3.5 |
15 |
683 |
|||
|
140.0 |
4.8 |
2.5 |
20 |
752 |
|||
|
112.0 |
5.7 |
2.8 |
25 |
810 |
|||
|
93.3 |
6.5 |
2.3 |
30 |
861 |
|||
|
70.0 |
8.1 |
1.7 |
40 |
948 |
|||
|
56.0 |
10 |
1.4 |
50 |
1021 |
|||
|
46.7 |
11 |
1.1 |
60 |
NMRV030 |
56A2 |
1085 |
|
|
35.0 |
13 |
0.9 |
80 |
1194 |
|||
|
280.0 |
2.7 |
6.7 |
5 |
NMRV030 |
56B4 |
597 |
|
|
186.7 |
3.9 |
4.6 |
7.5 |
683 |
|||
|
140.0 |
5.0 |
3.6 |
10 |
752 |
|||
|
93.3 |
7.1 |
2.5 |
15 |
861 |
|||
|
70.0 |
9.0 |
2.0 |
20 |
948 |
|||
|
56.0 |
10 |
2.0 |
25 |
1021 |
|||
|
46.7 |
12 |
1.7 |
30 |
1085 |
|||
|
35.0 |
14 |
1.2 |
40 |
1194 |
|||
|
28.0 |
17 |
1.0 |
50 |
1286 |
|||
|
23.3 |
19 |
0.9 |
60 |
1367 |
|||
|
180.0 |
4.1 |
4.9 |
5 |
NMRV030 |
63B6 |
692 |
|
|
120.0 |
5.9 |
3.4 |
7.5 |
792 |
|||
|
90.0 |
7.6 |
2.6 |
10 |
871 |
|||
|
60.0 |
11 |
1.9 |
15 |
997 |
|||
|
45.0 |
13 |
1.5 |
20 |
1098 |
|||
|
36.0 |
15 |
1.5 |
25 |
1183 |
|||
|
30.0 |
17 |
1.2 |
30 |
1257 |
|||
|
22.5 |
21 |
1.0 |
40 |
1383 |
|||
|
18.0 |
24 |
0.7 |
50 |
1490 |
|||
|
28.0 |
19 |
2.0 |
50 |
NMRV040 |
56B4 |
2475 |
|
|
23.3 |
21 |
1.7 |
60 |
2630 |
|||
|
17.5 |
26 |
1.3 |
80 |
2895 |
|||
|
14.0 |
29 |
1.0 |
100 |
3118 |
|||
|
30.0 |
19 |
2.6 |
30 |
NMRV040 |
63B6 |
2419 |
|
|
22.5 |
24 |
1.9 |
40 |
2662 |
|||
|
18.0 |
27 |
1.5 |
50 |
2868 |
|||
|
15.0 |
31 |
1.3 |
60 |
3047 |
|||
|
11.3 |
37 |
1.0 |
80 |
3354 |
|||
|
9.0 |
41 |
0.8 |
100 |
3490 |
|||
|
15.0 |
32 |
2.3 |
60 |
NMRV050 |
63B6 |
4183 |
|
|
11.3 |
37 |
1.8 |
80 |
4604 |
|||
|
9.0 |
42 |
1.3 |
100 |
4840 |
|
